• The world's first small-scale central differential structure, providing a responsive feel even in a small scale.
• The fully enclosed triangular support frame and support plate of the central differential form a triangular structure
• Dual Specification Battery Compartment Design,Accommodating a 3s-5000mAh large battery for extended runtime without the need for frequent battery changes.
• With a strong body structure and enlarged gearing, you can hit high speeds in virtually any environment - off-road, dirt and grass, parking lots, and paved and asphalt surfaces.
• Equipped with a center differential structure for enhanced maneuverability and full-throttle freedom over rough terrain, slick surfaces and loose dirt.

Description:

INNOVATIVE DESIGN-

The world's first small-scale central differential structure, providing a responsive feel even in a small scale.

- READY TO RUN -

Ready to Run (RTR) competition grade RC is fully assembled with everything needed as well as a 3S (2200 mAh) battery

- KEY FEATURES -

• Small-Scale Central Differential Structure: The world's first small-scale central differential structure, providing a responsive feel even in a small scale.
• Geometric Structural Design: The fully enclosed frame central differential triangle bracket and support plate form a triangular structure, creating an upper and lower positive and negative double triangular structure, greatly enhancing the rigidity and strength of the chassis! This makes the body more sturdy, offering better protection to the frame from bending during collisions.
• Dual Specification Battery Compartment Design: Accommodating a 3s-5000mAh large battery for extended runtime without the need for frequent battery changes.
• Easy-Access Modular Design: Separate, easily removable chassis modules for the power system, electronics, and differential components make routine maintenance fast and simple.
• Powerful Steering System: Dual crank steering system provides steering input to the front wheels for more precise maneuvering, equipped with 11KG servos for more torque and 7075 hardened gears for more torque and durability.
• Extra Durable Gear Differentials: Adopts a 1:10 scale gear, making gears more durable and providing stronger reliability for high-speed and high-torque operation.
• Easy-Access Differentials: Front and rear differentials can be quickly and easily adjusted and serviced quickly and easily, with only four screws required to connect the gear differentials at each end of the Total Terminator.
• Rugged Reinforced Designr: Through clever design and sophisticated structural reinforcement, the frame has been able to significantly increase its robustness and exhibit greater toughness.
• CNC 7075 Shock Mounts: Shock absorbers made from CNC 7075 aluminum alloy are stronger and more durable.
• Full-Enclosed Front and Rear Impact Protection: Adoption of full-encompassing front and rear crash cushioning and absorbing structure, which can more effectively release the force in the event of an impact, and protect the body from injury in all aspects.
• Professional Hobby Grade Transmitter with Receiver: 2.4GHz 4-Channel Transmitter with 150m control distance, 0.1s response time
• Strong and Durable Car Shell: The car shell is made of PVC material, which can absorb the impact in case of collision and reduce the possibility of body damage, and the car shell comes with a portable body clasp to prevent loss.

Specifications:

GEOMETRIC STRUCTURAL DESIGN

The fully enclosed frame central differential triangle bracket and support plate form a triangular structure, creating an upper and lower positive and negative double triangular structure, greatly enhancing the rigidity and strength of the chassis! This makes the body more sturdy, offering better protection to the frame from bending during collisions.

EASY-ACCESS MODULAR DESIGN

Separate, easily removable chassis modules for the power system, electronics, and differential components make routine maintenance fast and simple.

SMALL-SCALE CENTRAL DIFFERENTIAL STRUCTURE

The world's first small-scale central differential structure, providing a responsive feel even in a small scale.

EXTRA DURABLE GEAR DIFFERENTIALS

adopts a 1:10 scale gear, making gears more durable and providing stronger reliability for high-speed and high-torque operation.

EASY-ACCESS DIFFERENTIALS

Front and rear differentials can be quickly and easily adjusted and serviced quickly and easily, with only four screws required to connect the gear differentials at each end of the Total Terminator.

RUGGED REINFORCED DESIGN

Through clever design and sophisticated structural reinforcement, the frame has been able to significantly increase its robustness and exhibit greater toughness.

CNC 7075 SHOCK MOUNTS

Shock absorbers made from CNC 7075 aluminum alloy are stronger and more durable.

FULL-ENCLOSED FRONT AND REAR IMPACT PROTECTION

Adoption of full-encompassing front and rear crash cushioning and absorbing structure, which can more effectively release the force in the event of an impact, and protect the body from injury in all aspects.

Alloy Standard
RTR Version

Specifications:

Name- RZ001G-A
Supported Battery- 2-3S
Speed - 60-80kph
Dimensions
Wheelbase: 251mm
Length: 410mm
Width: 288mm
Height: 172mm
Motor: 2852-3100kv
Cooling Fan & Fin: Yes
ESC: 45A, Support 2-3S Battery
Battery: 2200mAh 3S Lipo Battery
Servo: 11kg, 7075 Aluminum Gear
Transmitter: 4-channel Transmitter
150-meter controlled range
Pinion Gear: 0.53M/48P 16-19T Chrome Steel Pinion Gear
Spur Gear: 0.53M/48P 65T Quality Alloy Metal Spur Gear
Input Gear: 1M-11T Quality Alloy Metal
Differential Gear 1M-34T Quality Alloy Metal
Main Driveshaft: Steel Split Center Differential
Transmission Method: Central Differential Transmission
CVD: Steel CVD
Tire Size- 104mm
Shock Absorber: Oil-filled Metallic Shock Absorber
Suspension Arm: Double-Triangle Nylon
Body Clip: Anti-lost R Body Clip
Receiver Box: Waterpoof
Battery Compartment: 2 in 1 Battery Compartment
Small: 110x36x30mm

Big: 140x30x45mm
Chassis: 2.5mm Aluminum
Shock Tower: 4mm 7075 Aluminum, CNC
Suspension Arm Mount: 4.5mm Aluminum
Upper Deck: Aluminum
Motor Mount: Aluminum, support Dia.28mm Series Motor, adjustable
Steering Link: Aluminum

Car Body: 1.2mm PVC.

Rlaarlo Metal MINI 1:10 Scale RTR Brushless Monster Truck, RZ001G-A- RC now available in India.
